ThingMagic Nano Embedded UHF RFID Module Developer Kit - ThingMagic Nano Developer Kit allows you to utilize the wide RF output range (0 dBm to +27 dBm) of the Nano, a feature that is important for the read/write requirements for RFID-enabled printers and tag commissioning stations. It features a surface mount package designed for the efficiency of SMT manufacturing, driving down the total cost for embedding RFID in volume applications, including handheld devices, consumables authentication, device configuration and access control. This developer kit is the perfect way to make the most of your M6e-Nano reader module.

ThingMagic Nano embedded UHF RFID module saves space, battery power, and money; it is small enough to fit just about anywhere, has low power consumption, and features a surface mount package to drive down the total embedding cost. It does all of this without sacrificing any flexibility or power as it is extremely portable, has a wide RF output range, and is designed to be used in high volume applications. When you need to build a reader with a tiny, effective module, look no further.

ThingMagic Nano Embedded UHF RFID Reader Module reader module enables you to build a reader with serial and USB interfaces to support both board-to-board and board-to-host connectivity. The module development kit gives you everything you need to connect to a PC and start reading tags. The Mercury API is loaded on your host processor so you can write software to control the module in the DevKit chassis. The Mercury API supports the entire line of ThingMagic finished readers and embedded RFID modules.

Full schematics of the DevKit are available to support building of your own application-specific reader. The Universal Reader Assistant reduces complexity for novice users but still allows for low-level control for advanced developers by enabling testing and tuning of reader settings, antennas, and tags for your workflow.

Features:
    Can support a monostatic antenna through board-edge connection
    Small size, barely larger than a quarter
    Separate read and write levels, command adjustable
    High tag read rate

ThingMagic Nano Embedded UHF RFID Reader Module Developer Kit includes:
    M6e-Nano Embedded UHF RFID Module Unit
    Test Chassis Unit
    6 ft RP-TNC to RP-TNC Antenna Cable
    USB Cable
    9V AC Power Adapter + Plug Adapter Kit (US, UK, EU, AU)
    Antenna Unit (7.5 in 7 dBiC patch antenna)
    Packet of Sample Tags
    ThingMagic Mercury API
